I technical parameters

1 test load: 80~1000g

2 under load: 5kg

3 test trip: 10~50mm (adjustable)

4 stroke display: scale indication.

5 test speed: 0~60rpm/min

6 load weight: two 50100200500g

7 friction medium: standard test pencil eraser: Standard Test: 6B-9H, #75125

Alcohol friction head (can be customized)

8 three kinds of grinding head: rubber abrasion resistant, wear-resistant pencil head abrasion head

9 friction hammer center height: adjustable

10 display mode: all Chinese LCD LCD display

11 fixture fixed position: adjustable

12 working power supply: 220V/50Hz AC

13 power: 90W

14 machine weight: 30kg

15 LCD display test speed

16 LCD display test count and set number

17 count and set value 0~999999 times

18 soft setting LCD contrast and backlight time,

19 using embedded microprocessor technology, higher reliability

20 optional automatic adding alcohol device.
